Simple problems on relativistic energy and momentum
Einstein showed that the Lorentz transformations were the correct way to switch between the coordinate systems of different inertial frames of reference. He also taught us that Newton’s classical laws were not proper relativistic descriptions. For instance, Newtonian momentum \(\mathbf{p} = m \mathbf{v}\) and kinetic energy \(E_\text{k} = \dfrac{1}{2}mv^2\) lose their accuracy at velocities approaching the speed of light.
Instead, relativistic momentum is given by:
\[\mathbf{p} = \dfrac{m \mathbf{v}}{\sqrt{1 - \dfrac{v^2}{c^2}}}.\]
And the relativistic total energy of a particle with rest mass \(m\) is expressed as:
\[E_{\text{tot}} = \dfrac{mc^2}{\sqrt{1 - \dfrac{v^2}{c^2}}}.\]
In this article, we will solve three foundational problems:
- Prove that for a particle travelling at \(c\), the magnitude of the relativistic energy is given by \(E = pc\).
- Demonstrate that the energy-momentum relation \(E_{\text{tot}}^2 = p^2c^2 + m^2c^4\) holds universally for a particle with any invariant mass \(m\) travelling at any velocity \(v\).
- Given a proton of rest mass \(m_p\), calculate its exact velocity when its relativistic translational kinetic energy equals four times its rest mass energy.
Problem I
Since energy \(E\) is to be expressed in terms of momentum \(p\), we isolate \(m\) from the scalar magnitude of momentum \(p = \dfrac{mv}{\sqrt{1 - v^2/c^2}}\):
\[m = \dfrac{p \sqrt{1 - \dfrac{v^2}{c^2}}}{v}.\]
Substituting this expression for \(m\) into the equation for total relativistic energy yields:
\[E_{\text{tot}} = \dfrac{\left(\dfrac{p \sqrt{1 - \dfrac{v^2}{c^2}}}{v}\right)c^2}{\sqrt{1 - \dfrac{v^2}{c^2}}}.\]
The Lorentz factor term \(\sqrt{1 - v^2/c^2}\) cancels out directly:
\[E_{\text{tot}} = \dfrac{pc^2}{v}.\]
For a massless particle travelling at the speed of light (\(v = c\)), this expression simplifies immediately to:
\[E_{\text{tot}} = \dfrac{pc^2}{c} = pc.\]
Problem II
The fundamental relativistic energy-momentum invariant is:
\[E_{\text{tot}}^2 = p^2c^2 + m^2c^4.\]
To verify that this relation holds identically for any velocity \(v < c\) and mass \(m\), we substitute the definitions of \(E_\text{tot}\) and \(p\):
\[\left(\dfrac{mc^2}{\sqrt{1 - \dfrac{v^2}{c^2}}}\right)^2 = \left(\dfrac{mv}{\sqrt{1 - \dfrac{v^2}{c^2}}}\right)^2 c^2 + m^2c^4.\]
Subtracting the right-hand terms from the left-hand side:
\[\dfrac{m^2c^4}{1 - \dfrac{v^2}{c^2}} - \dfrac{m^2v^2c^2}{1 - \dfrac{v^2}{c^2}} - m^2c^4 = 0.\]
Combining the terms over the common denominator \(1 - v^2/c^2\):
\[\dfrac{m^2c^4 - m^2v^2c^2}{1 - \dfrac{v^2}{c^2}} - m^2c^4 = \dfrac{m^2c^4\left(1 - \dfrac{v^2}{c^2}\right)}{1 - \dfrac{v^2}{c^2}} - m^2c^4 = m^2c^4 - m^2c^4 = 0.\]
The equality holds identically for all permissible values of \(m\) and \(v\).
Problem III
.jpg)
The total relativistic energy is the sum of translational kinetic energy and rest mass energy:
\[E_{\text{tot}} = E_{\text{k}} + E_{\text{mass}}.\]
We are given that the proton’s kinetic energy is four times its rest mass energy:
\[E_{\text{k}} = 4E_{\text{mass}}.\]
Therefore, the total energy of the proton is:
\[E_{\text{tot}} = 4E_{\text{mass}} + E_{\text{mass}} = 5E_{\text{mass}} = 5m_p c^2.\]
Equating this to the relativistic formula for total energy:
\[\dfrac{m_p c^2}{\sqrt{1 - \dfrac{v^2}{c^2}}} = 5m_p c^2.\]
Dividing both sides by \(m_p c^2\):
\[\dfrac{1}{\sqrt{1 - \dfrac{v^2}{c^2}}} = 5.\]
Squaring and solving for \(v^2/c^2\):
\[1 - \dfrac{v^2}{c^2} = \dfrac{1}{25},\]
\[\dfrac{v^2}{c^2} = 1 - \dfrac{1}{25} = \dfrac{24}{25},\]
\[v = \dfrac{\sqrt{24}}{5} c = \dfrac{2\sqrt{6}}{5} c \approx 0.9798 c.\]
The proton is travelling at approximately 98% of the speed of light relative to the laboratory frame.
